Pellet Stove Lena Plus Top stone  9,2 KW Edilkamin.

SEND MAIL FOR DISCOUNT AND AVAILABILITY

€3,060.00
Tax included
 In Stock

Description

Pellet Stove Lena Plus Top stone  9,2 KW Edilkamin.

• Cast iron combustion chamber

• Smoke outlet Ø 8 cm rear, male

• Daily/weekly program

• EASY TIMER function

• RELAX function (Deactivatable hot air ventilation)

• Built-in WI-FI

• “Mind remote” remote control

• Voyant de réserve pellet

• system Leonardo

• ARear hot air duct Ø 6 cm, front and ducted fan separate settings through remote control, with choice to fit an optional room probe for the ducted fan handling.

AVAILABLE MODELS:

• Steel and inserts Black steel

• Steel and inserts Matt white ceramic

• Steel and inserts Soapstone

Optional:

• Kit airKare

• LTE ADVANCED 4G telephone dialer

• Kit warm-air ducting Ø 6 cm

• Kit warm-air ducting Ø 8 cm

• NTC Room probe for temperature reading in ductingn

• Air diverter kit

Technical data min/max

width cm 50

depth cm 49

height cm 100

useful output kW 9,2

efficiency % 88,5

fuel consumption (pellet) kg/h 0,9/2,2

tank capacity kg 24

autonomy h 11/27

Ø combustion product outlet cm 8

Ø external air intake cm 4

total weight kg 115/123/117

vol. that can be heated 240

OPERATING PRINCIPLE AND GENERAL SPECIFICATIONS

The devices are designed to produce hot air by automatically burning wood pellets.

All phases are controlled by the electronic controller's software, which guarantee's high efficiency and low emissions in total safety.

The hot air is delivered to the room in which the device is installed via a grille on the front of the stove and, if so desired, may be sent to adjacent rooms via pipes.

The device can be controlled with a remote control, and remote ignition devices can also be hooked up to it.

GENERAL OPERATIONAL SCHEME

For the scheme specific to your model, refer to the technical data sheet enclosed with the product.

1 = pellet hopper with top loading hatch

2 = screw for conveying the pellets from the hopper to the combustion chamber

3 = screw gearmotor

4 = pellet combustion hearth

5 = electric heating element for igniting the pellet

6 = centrifugal fan for extracting the combustion fumes

7 = fumes outlet port for connection to flue

8 = synoptic panel for controlling/monitoring the device's operation

9 = combustion air intake port

10 = heat exchanger tubes for producing hot air

11 = grille for delivering the hot air to the room

12 = ports for delivering hot air to adjacent rooms

13 = hot air fan

Data sheet

Edilkamin
Data sheet
Energetic Class
A+
Environmental Class
4 Stars
